Port Size |
M5 |
|
Operation |
Direct Acting |
|
Type |
2/2 Single Coil |
|
Body Material |
Stainless Steel |
|
Seals Material |
FKM |
|
Operating Pressure Differential |
0 to 116psi (0 to 8bar) |
|
Media Temperature |
-13°F to 149°F (-25°C to 65°C) |
|
Orifice Size |
3/64 Inch/1.2 (mm) |
|
Flow Coefficient |
0.04Cv (0.05Kv m3/h) |
|
Voltage |
24VDC, 110VDC, 24VAC, 220VAC |
|
Coil |
Fly Coil |
|
Media |
Air, water |
FEATURES AND BENEFITS
APPLICATIONS
